UNIVERSAL

Optimate usb charger kit sae connection

Combined 2400mA USB charger with 3-LED battery monitor and vehicle battery protection LENGTH: 8cm CHARGING CONNECTOR (INPUT): 2-pin SAE CHARGING CONNECTOR (OUTPUT): 1x USB CHARGE POWER (AMP): 2400mA @5V OPERATION: fully automatic Standby mode: the USB output will be turned off when the engine stopped one hour ago or immediately if the voltage drops below 12.4V. 2 LED battery monitor (if there is no USB output) - battery condition is displayed every 5 seconds. Protection against short circuit, overheating and overload. INPUT: 12V system of vehicle with 12V lead-acid battery or 12.8V lithium battery. OPERATION (Voltage) USB ON - 13.3V to 18V - unlimited USB output, USB LED on. Provides power via USB when the vehicle engine is charging the battery. USB 1 HOUR - 12.4V to 13.3V - 1 hour USB output, USB LED on. Goes into standby mode after 1 hour or at voltage < 12.4V. STANDBY MODE - Voltage monitoring, reactivates when the vehicle battery voltage again exceeds 13.3V. AGM/LFP MONITOR - LED flashes every 5 seconds when the battery charge is = 50%, sufficient to start the vehicle's engine. LED LFP: 13.1V to 13.3V. LED AGM: 12.4V to 13.1V. NO LED < 12.4V. OFF = 9 V STYLE: Fully sealed electronic housing with multiple LEDs. Unique sealing with cap for the USB connection. Any USB cable is sealed when plugged in. WARRANTY: 3 year limited exchange warranty.
